Enduro

Self-propelled 4-row sieving harvester

The result of over 30 years' experience in potato harvesting technology

The Enduro is a 4-row self-propelled sieving harvester on tyres. Product-friendliness, capacity and ease of use characterise this harvester. The Enduro is the result of the combination of our own extensive experience and input from agricultural contractors and potato growers. On the one hand, the machine on tyres is equipped with new technologies in ground pressure, product cleaning and flow, and buffer capacity. On the other hand, it also contains the familiar Dewulf technology that has proven its added value time and again on many potato fields throughout the years.

Large sieving and cleaning capacity

The Enduro has optimal sieving capacity throughout the machine, partly because there are no constrictions along the sieving webs. The driver can easily and steplessly adjust the inclination of the cleaning module between 0° and 12°, based on the cleaning need in the field. Moreover, the module with axial rollers can be bypassed at any inclination angle for greater flexibility.

Step up to the next level with Level X

The right machine settings make a major difference in the harvesting process. With Level X, Dewulf brings together data, smart technology and automation to support the operator and get the most out of the Enduro. This makes it easier to achieve the optimal balance between capacity and harvesting quality.

Level X is available in three different packages, each with its own focus and clear benefits:

  • Level X Bronze: comes as standard and provides insights via the integrated IoT platform into GPS location, consumption, machine speed and mode, harvested area, productivity and more.
  • Level X Silver: gives the operator greater control over the quality of the harvesting process with a state-of-the-art camera system, saved machine settings, Remote View, slow motion and casting integration.
  • Level X Gold: takes automation to the next level. Based on sensors, data and AI-driven analyses, the machine automatically adjusts its settings to the crop, soil and conditions, with the aim of maintaining consistent quality while making optimal use of the machine’s capacity.

Patented ring elevator: ‘Fill-Tastic’

The Enduro is our first harvester to make use of our patented, new ring elevator. Capacity and product-friendliness were combined in this ring elevator, which was given the name ‘Fill-Tastic’. The ring elevator has a high capacity of 200 tonnes/h and achieves this at a very potato-friendly speed.

Largest buffer capacity in its segment

The Enduro's 2-part bunker with discharge elevator, with a practical volume of 12,3 m³, is the largest in its segment. Because the fixed bunker floor is followed by a discharge elevator with bar webs, excess soil is sieved out during unloading. The discharge elevator with hinged top reaches over 4 full rows, so you can always easily unload into a tipper.

Extremely low ground pressure

The Enduro's high manoeuvrability puts it in a class of its own. Moreover, in terms of ground pressure, the harvester achieves the best figures in its segment with a pressure as low as 1.5 kg/cm2. This is achieved through the ‘Soil-Saver’ technology: a sophisticated system of weight distribution over three axles for minimal ground pressure. Because the machine's centre of gravity is located further to the rear, the Enduro also ensures that the ridges will not be damaged by the front wheels, even in wet conditions.

Comfortable and easy operation

The roomy Claas cabin provides the driver with a comfortable and well-organised working environment with an excellent view of the harvesting unit. The ergonomic N-joystick and well-organised touchscreen control unit ensure simple and intuitive operation. The Premium cabin raises comfort and ergonomics to an even higher level, with among others a swivelling leather driver’s seat with ventilation, a refrigerator and sun curtains all around. This keeps driver comfort at the forefront, even during long harvesting days.

Enduro

Why choose for Enduro

  • Largest bunker in its segment
  • Lowest ground pressure in its class
  • Unique ring elevator with high capacity

Configure your machine

Create the Enduro based on your preferences and requirements. Save your result and request a quote in 1 click!

To the configurator

Photo gallery

Technical specifications

  • ■ = standard
  • o = Optional
  • - = Not applicable
Width of sieving conveyor 1 [mm] 2 x 1460 (4 x 75)
Hydraulically driven cutting discs ■
Diabolo kit + driven cutting discs o
APC (Automatic Pressure Control) ■
Syncro Flow ■
DAS (Dewulf Automatic Steering) o
ADC (Automatic Depth Control) ■
Length sieving conveyor 1 [mm] 1870
Length sieving conveyor 2 [mm] 3250
Length sieving conveyor 3 [mm] 2280
Length sieving conveyor 4 [mm] 2370
Haulm chopper with side discharge o
2 haulm rollers ■



Rotary agitator in sieving conveyor 1 o
Two eccentric agitators in sieving web 2 ■
2 star agitators in sieving conveyor 2 o
Eccentric/star agitator in sieving conveyor 3 ■
Hedgehog unit ■
Axial module ■
Easyclean module o
Axial module with bypass o
Total length [mm] 14 870
Total width [mm] 3500
Total height [mm] 4000
Weight from [kg] 27 000
Front wheels 2 x Alliance 270/95 R48 VF: •
  2x VF Mitas 270/95 R48: o
Rear wheels 4 x BKT 750/65 R26: •
  4 x Michelin 750/65 R26 VF: o

Enduro is suited for these crops:

Potatoes

Potatoes

Carrots

Carrots

Onions

Onions

Red beet

Red beet

Celeriac

Celeriac

Parsnip

Parsnip

Turnips

Turnips

Chicory

Chicory

Salsify

Salsify
